Z3050x16/1
Radial Drilling Machine is suitable for drilling, reaming, reaming, plane and tapping of medium and large parts, and can be used under the condition of process equipment Perform boring.
Radial drilling machine safety precautions:
1. The diameter of the iron rod used for lifting the machine tool is 40mm, and the length of both sides of the machine tool is not less than 300mm. The steel wire rope should be padded with cork or felt pad between the surface of the machine tool. 2, the headstock lifting must loosen the fastening bolt of the insert, the headstock lifting must be locked after the bolt, do not allow the bolt to shake the headstock hard, so as not to damage the related parts.
3. The machine tool spindle is not allowed to touch the spindle by hand before it completely stops rotating, so as not to hurt people.
4, when the machine is rotating, it is absolutely not allowed to change speed, otherwise it will cause gear damage.
5. The power supply must be turned off when cleaning and maintaining the machine tool.
6, the machine tool cutting should take appropriate measures to prevent iron filings splashing injury.
7. When unloading the tool with the retracting wedge, the spindle must be returned to the original position.
8. Check whether the position of each handle is correct before starting the machine.
9. When the machine tool is used for the first time or is not used for a long time, the machine tool should be run for a few minutes at low, medium and high speeds. 10, the lubricating oil used in the machine tool must be pure and acid-free, does not contain moisture and other impurities. After the machine tool is used for a month, the first oil is changed, and the oil can be replaced every three to six months according to the use of the oil. When the oil is changed, the old oil is discharged first, and then the clean new oil is injected after cleaning with pure kerosene.
